9.3 Network Parameters
This section explains the network parameter list and parameter details.
mn, **, N and M in the Parameter No. field of this section
mn, **, N and M in the Parameter No. field of this section indicate the following.
mn : Indicates a "start I/O No. 16" value.
** : Indicates any value.
N : Indicates the module number.
M : Indicates the network type.
Note5
Table9.29 Setting for CC-Link IE controller network and MELSECNET/H ( (1), (2) in this section)
M Network type
1H
CC IE Control (Control station)
Note9.6
, MELSECNET/H mode (Control station),
MELSECNET/H. Extended mode (Control station), MELSECNET/10 mode (Control
station)
2H
CC IE Control (Normal station), MELSECNET/H mode (Normal station),
MELSECNET/H. Extended mode (Normal station), MELSECNET/10 mode (Normal
station)
5H MELSECNET/H (Remote master)
AH MELSECNET/H (Standby station)
BH MELSECNET/H mode multiplexed remote I/O network master station
DH
MELSECNET/H mode multiplexed remote I/O network sub-master station
(When there is no parameter setting)
EH
MELSECNET/H mode multiplexed remote I/O network sub-master station
(When there is parameter setting)
Table9.30 Setting for CC-Link ( (4) in this section)
M Network type
0H Master station
1H Local station
2H Standby master station
Note5
Basic
Note9.6
The Basic model QCPU cannot specify "CC IE Control (Control station)".
Basic
Note9.6
