64
-
'09•SRK-DB-087D
Jumper wire (JA2)
(2)ࠉUnit ON/OFF button
(a) Operation
(b) Details of operation
(3)ࠉAuto restart function
(a)
(b)
(i)
(ii)
(4)Custom cord switching procedure
(a) Modifying the indoor printed circuit board
(b) Modifying the wireless remote control
(i)
(ii)
Cut
Function
Operation mode
Room temperature
setting
Fan speed
Flap/Louver
Timer switch
COOL
DRY
HEAT
Unit ON/OFF button
whether to go into the COOL, DRY or HEAT modes.
room
Jumper wire (J1)
㻾㻌㻸㻌㻲㻌㻡㻌㻜㻌㻡㻌㻭㻌㻝㻌㻜㻌㻞
00
'09•SRK-DB-087D
(2)ࠉUnit ON/OFF button
(a) Operation
(b) Details of operation
(3)ࠉAuto restart function
(a)
(b)
(i)
(ii)
(J170)
Function
Operation mode
Indoor temperature
setting
Fan speed
Flap/Louver
Timer Switch
COOL
DRY
HEAT
Unit ON/OFF button
Jumper wire (J170)
When two air-conditioners are installed in the room, use this setting when the two air-conditioners are not operated with one
wireless remote control. Set the wireless remote control and indoor unit.
(a)
ࠉSetting the wireless remote control
(i) Pull out the cover and take out batteries.
(ii) Cut the switching line next to the battery with wire cutters.
(iii) Insert batteries. Close the cover.
(b)
ࠉSetting an indoor unit
(i) Turn off the power source, and turn it on after 1 minute.
(ii) Point the wireless remote control (that was set according to the procedure
described on the left side) at the indoor unit and send a signal by pressing
the ACL switch on the wireless remote control.
Since the signal is sent in about 6 seconds after the ACL switch is pressed,
point the wireless remote control at the indoor unit for some time.
(iii) Check that the reception buzzer sound "Peep" is emitted from the indoor unit.
At completion of the setting, the indoor unit emits a buzzer sound "Peep".
(If no reception sound is emitted, start the setting from the beginning again.)
Disconnect
(4)ࠉInstalling two air-conditioners in the same room
wireless wireless
Reception
Pii
Jumpre wire (J1)
Unit ON/OFF button
Cut
TIME SETUP ACL
Reception
Peep
