Motorola CM360 Service Manual

Service Aids 2-19
9.0 Service Aids
Table 2-4 lists the service aids recommended for working on the radio. While all of these items are
available from Motorola, most are standard workshop equipment items, and any equivalent item
capable of the same performance may be substituted for the item listed.
Table 2-5 Service Aids
Motorola Part
No.
Description Application
RLN4460_ Portable Test Set Enables connection to audio/accessory jack.
Allows switching for radio testing.
GMVN5034A Customer Programming
Software (CPS) and Tuner
CDROM (MDC)
Programs customer options and channel data.
Tunes hardware parameters, front end,
power, deviation etc.
GMVN5033A Customer Programming
Software (CPS) and Tuner
CDROM (5-Tone)
Programs customer options and channel data.
Tunes hardware parameters, front end,
power, deviation etc.
RKN4081_ Programming Cable with
Internal RIB
Includes radio interface box (RIB) capability.
FKN8096_ Data/Flash Adapter Used with RKN4081 (10 to 8 pin adapter for
front Telco connector with CPS/Flash switch
for programming/flashing only).
RKN4083_ Mobile Programming/Test Cable Connects radio to RIB (RLN4008_) via rear
accessory connector
FKN8113_ Adapter Cable Used with RKN4083 (20 to 16 pin adapter for
rear accessory connector).
GTF374_ Program Cable Connects RIB to Radio microphone input.
RLN4008_ Radio Interface Box Enables communications between radio and
computer’s serial communications adapter.
HLN8027_ Mini UHF to BNC Adaptor Adapts radio antenna port to BNC cabling of
test equipment.
GPN6133_ Power Supply Provides the radio with power when bench
testing.
EPN4040_ Wall-Mounted Power Supply Used to supply power to the RIB (UK).
EPN4041_ Wall-Mounted Power Supply Used to supply power to the RIB (Euro).
8180384N64 Housing Eliminator (25W) Test Fixture used to bench test the radio pcb.
3080369B71 Computer Interface Cable Connects the RIB to the Computer (25-pin).
3080369B72 Computer Interface Cable Connects the RIB to the Computer (9-pin)
(Use for IBM PC AT - other IBM models use
the B71 cable above).
6686119B01 Removal Tool Assists in the removal of radio control head.
