Motorola CM360 Service Manual

Test Equipment 2-21
10.0 Test Equipment
Table 2-5 lists test equipment required to service the radio and other two-way radios.
Table 2-6 Recommended Test Equipment
Motorola Part
No.
Description Characteristics Application
R2600_NT Comms System
Analyzer (non MPT)
This monitor will
substitute for items with
an asterisk *
Frequency/deviation meter
and signal generator for wide-
range troubleshooting and
alignment
*R1072_ Digital Multimeter AC/DC voltage and current
measurements
*R1377_ AC Voltmeter 100 µV to 300 V,
5Hz-1MHz,
10 Megohm input
impedance
Audio voltage
measurements
WADN4133 Delay
Oscilloscope
2 Channel 40 MHz
bandwidth,
5 mV/cm - 20 V/cm
Waveform measurements
R1440_
0180305F17
0180305F31
0180305F40
RLN4610_
T1013_
Wattmeter,
Plug-in Elements
Plug-in Elements
Plug-in Elements
Carry case
RF Dummy Load
Thruline 50-Ohm,
±5% accuracy
10W, 25 - 60 MHz
10W, 100 - 250 MHz
10W, 200 - 500 MHz
Wattmeter and
6 elements
Transmitter power output
measurements
S1339_ RF Millivolt Meter 100mV to 3 VRF,
10 kHz to 1.2 GHz
RF level measurements
R1011_/220V 220V Power
Supply
0-40V, 0-40A Programmable
