Motorola Radius CM300 User Manual

VHF 1–25 W Band 2 PCB 8488977U01 (rev. P9) / Schematics 4-19
2.1 VHF2 PCB 8488977U01 (rev. P9) Parts
List 1–25 W
Circuit
Ref.
Motorola
Part No.
Description
C1000 2113740F59
CAP CHIP REEL CL1 +/-30 220
C1001 2311049A08 KEMET CAPS
C1002 2111078B59 CHIP CAP RF 470 5 NPO 100V
C1003 2111078B59 CHIP CAP RF 470 5 NPO 100V
C1004 2111078B47 CAP CHIP RF 150 5 NP O 100V
C1005 2111078B47 CAP CHIP RF 150 5 NP O 100V
C1006 2111078B47 CAP CHIP RF 150 5 NP O 100V
C1007 NOT PLACED –
C1008 2111078B42 CAP CHIP RF 100 5 NPO 100V
C1009 2111078B42 CAP CHIP RF 100 5 NPO 100V
C1010 2111078B42 CAP CHIP RF 100 5 NPO 100V
C1011 2111078B38 CAP CHIP RF 68 5 NPO 100V
C1012 2111078B36 CAP CHIP RF 56 5 NPO 100V
C1013 2111078B36 CAP CHIP RF 56 5 NPO 100V
C1014 NOT PLACED –
C1015 2111078B34 CAP CHIP RF 47 5 NPO 100V
C1016 2111078B29 CAP CHIP RF 33 5 NPO 100V
C1017 2111078B22 CAP CHIP RF 22 5 NPO 100V
C1018 NOT PLACED –
C1019 2111078B16 CAP CHIP RF 13 5 NPO 100V
C1020 2111078B15 CAP CHIP RF 12 5 NPO 100V
C1021 2111078B13 CAP ALT E16
C1022 2111078B09 CAP ALT E17
C1023 2111078B21 CAP ALT E35
C1024 2111078B05 CAP ALT E19
C1025 2111078B05 CAP ALT E19
C1027 2311049A45 CAP TANT CHIP 10 10 35
C1028 2113743K15 CER CHIP CAP .100UF
C1029 2113743K15 CER CHIP CAP .100UF
C1030 2113743E07 CER CHIP CAP .022UF
C1031 2113743E07 CER CHIP CAP .022UF
C1032 2113743E07 CER CHIP CAP .022UF
C1033 2113743E07 CER CHIP CAP .022UF
C1034 2113740F59
CAP CHIP REEL CL1 +/
-30 220
C1035 2113743E07 CER CHIP CAP .022UF
C1036 2113743E07 CER CHIP CAP .022UF
C1037 2113743E07 CER CHIP CAP .022UF
C1038 NOT PLACED –
C1039 2113743E07 CER CHIP CAP .022UF
C1040 2113741F33 CAP CHIP CL2 X7R REEL 2200
C1041 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1042 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1043 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1044 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1045 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1046 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1047 2113743K17
CAP CHIP .330 UF +80-20% 16V
C1048 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1049 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1050 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1051 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1052 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1053 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1054 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1055 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1056 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1057 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1058 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1059 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1060 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1061 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1062 2113741F25 CAP CHIP CL2 X7R REEL 1000
Circuit
Ref.
Motorola
Part No.
Description
C1063 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1064 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1065 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1066 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1067 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1068 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1069 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1070 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1071 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1072 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1073 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1074 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1075 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1076 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1077 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1078 2113740F59
CAP CHIP REEL CL1 +/
-30 220
C1079 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1080 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1081 NOT PLACED –
C1082 NOT PLACED –
C1083 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1084 2113740F59
CAP CHIP REEL CL1 +/
-30 220
C1085 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1086 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1087 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1088 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1089 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1090 NOT PLACED –
C1091 NOT PLACED –
C1092 NOT PLACED –
C1093 NOT PLACED –
C1094 NOT PLACED –
Circuit
Ref.
Motorola
Part No.
Description
C1095 NOT PLACED –
C1097 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1098 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1099 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1100 2113741F25 CAP CHIP CL2 X7R REEL 1000
C1101 2113740F51
CAP CHIP REEL CL1 +/-30 100
C1102 2113740F51
CAP CHIP REEL CL1 +/-30 100
C1103 2113741A57
CAP CHIP 33K +
-5%
(2160521A31)
C1104 2113741A53 CAP CHIP CL2 X7R REEL 22000
C1105 2113740F67
CAP CHIP CL1 +/-30 470 5%
C1106 2113740F67
CAP CHIP CL1 +/-30 470 5%
C1107 2113740F67
CAP CHIP CL1 +/
-30 470 5%
C1108 2113740F47
CAP CHIP REEL CL1 +/-30 68
C1109 2113740F59
CAP CHIP REEL CL1 +/
-30 220
C1110 2113740F59
CAP CHIP REEL CL1 +/-30 220
C1112 2113740F 59
CAP CHIP REEL CL1 +/
-30 220
C1113 2113740F59
CAP CHIP REEL CL1 +/-30 220
C1114 2113740F 59
CAP CHIP REEL CL1 +/
-30 220
C1115 2113740F59
CAP CHIP REEL CL1 +/-30 220
C1116 2113740F 59
CAP CHIP REEL CL1 +/
-30 220
C1117 2113740F43
CAP CHIP REEL CL1 +/-30 47
C1118 2113740F 39
CAP CHIP REEL CL1 +/
-30 33
C1119 2113740F39
CAP CHIP REEL CL1 +/-30 33
C1120 2113740F39
CAP CHIP REEL CL1 +/
-30 33
C1121 NOT PLACED –
C1122 2113740F59
CAP CHIP REEL CL1 +/
-30 220
C1123 2113740F59
CAP CHIP REEL CL1 +/-30 220
C1124 2113740F59
CAP CHIP REEL CL1 +/
-30 220
C1125 2113740F59
CAP CHIP REEL CL1 +/-30 220
C1126 2113740F59
CAP CHIP REEL CL1 +/
-30 220
Circuit
Ref.
Motorola
Part No.
Description
