4-44 VHF 25–45 W Band 2 PCB 8486487Z04 / Schematics
3.1 VHF 2 PCB 8486487Z04
Parts List 25–45 W
Circuit
Ref.
Motorola
Part No.
Description
C300 2113740F44 CAP, 51pF
C301 2311049A57 CAP, 10uF
C302 2113740F54 CAP, 130pF
C303 2113743K15 CAP, 0.1uF
C304 2113743E20 CAP, 0.1uF
C305 2113743E20 CAP, 0.1uF
C306 2113743E20 CAP, 0.1uF
C307 2113743E20 CAP, 0.1uF
C308 2113743E20 CAP, 0.1uF
C309 2113743E20 CAP, 0.1uF
C310 2113743E20 CAP, 0.1uF
C311 2113743E20 CAP, 0.1uF
C312 2113743E20 CAP, 0.1uF
C313 2113743E20 CAP, 0.1uF
C314 2113743E20 CAP, 0.1uF
C315 2113743E20 CAP, 0.1uF
C316 2113743E20 CAP, 0.1uF
C317 2113743E20 CAP, 0.1uF
C318 2113743E20 CAP, 0.1uF
C319 2113743E20 CAP, 0.1uF
C320 2113743E20 CAP, 0.1uF
C321 2113741F49 CAP, .01uF
C322 2113741F41 CAP, 4700pF
C323 2113741F25 CAP, 1000pF
C324 2113741F25 CAP, 1000pF
C325 2113741F25 CAP, 1000pF
C326 2113741F25 CAP, 1000pF
C327 2113741F25 CAP, 1000pF
C328 2113740F67 CAP, 470pF
C329 2113740F67 CAP, 470pF
C330 2113740F67 CAP, 470pF
C331 2113740F67 CAP, 470pF
C332 2113741F13 CAP, 330pF
C333 2113740L41 CAP, 91pF
C334 2113740L41 CAP, 91pF
C335 2113740L17 CAP, 9.1pF
C336 2113740L14 CAP, 6.8pF
C337 2113740F57 CAP, 180pF
C338 2113740F53 CAP, 120pF
C339 2113740F51 CAP, 100pF
C340 2113740F49 CAP, 82pF
C341 2113740F49 CAP, 82pF
C342 2113740F49 CAP, 82pF
C343 2113740F49 CAP, 82pF
C344 NOT PLACED CAP, 82pF
C345 NOT PLACED CAP, 82pF
C346 2113740F45 CAP, 56pF
C347 2113740F41 CAP, 39pF
C348 2113740F41 CAP, 39pF
C349 NOT PLACED CAP, 36pF
C350 2113740F40 CAP, 36pF
C351 2113740F40 CAP, 36pF
C352 2113740F39 CAP, 33pF
C353 2113740F38 CAP, 30pF
C354 2113740F38 CAP, 30pF
C355 2113740F38 CAP, 30pF
C356 NOT PLACED CAP, 30pF
C357 2113740F35 CAP, 22pF
C359 NOT PLACED CAP, 22pF
C360 NOT PLACED CAP, 22pF
Circuit
Ref.
Motorola
Part No.
Description
C361 2113740F33 CAP, 18pF
C362 2113740F33 CAP, 18pF
C363 NOT PLACED CAP, 12pF
C364 2113740F25 CAP, 8.2pF
C365 2113740F21 CAP, 5.6pF
C366 NOT PLACED CAP, 3.3pF
C367 NOT PLACED CAP, 2.7pF
C400 2113741F25 CAP, 1000pF
C401 2113743K15 CAP, 0.1uF
C402 2113743K15 CAP, 0.1uF
C403 2113743K15 CAP, 0.1uF
C404 2113743K15 CAP, 0.1uF
C405 2113743K15 CAP, 0.1uF
C406 2113743K15 CAP, 0.1uF
C407 2113743K15 CAP, 0.1uF
C408 2113743K15 CAP, 0.1uF
C410 2113743K15 CAP, 0.1uF
C411 2113741F25 CAP, 1000pF
C412 2113741F25 CAP, 1000pF
C413 2113741F25 CAP, 1000pF
C414 2113741F25 CAP, 1000pF
C415 2113741F25 CAP, 1000pF
C416 2113741F25 CAP, 1000pF
C417 2113741F25 CAP, 1000pF
C418 2113741F25 CAP, 1000pF
C421 2113743E07 CAP, .022uF
C422 2113741F25 CAP, 1000pF
C423 2113743K15 CAP, 0.1uF
C490 NOT PLACED CAP, 1uF
C602 2113741F25 CAP, 1000pF
C603 2113741F25 CAP, 1000pF
Circuit
Ref.
Motorola
Part No.
Description
C604 2113741F25 CAP, 1000pF
C605 2113741F25 CAP, 1000pF
C606 2113741F25 CAP, 1000pF
C607 2113741F25 CAP, 1000pF
C608 NOT PLACED CAP, 1000pF
C609 NOT PLACED CAP, 1000pF
C610 2113741F25 CAP, 1000pF
C611 2113741F25 CAP, 1000pF
C612 2113741F25 CAP, 1000pF
C613 2113741F25 CAP, 1000pF
C614 2113741F25 CAP, 1000pF
C615 2113741F25 CAP, 1000pF
C616 2113741F25 CAP, 1000pF
C617 2113741F25 CAP, 1000pF
C618 2113741F25 CAP, 1000pF
C619 NOT PLACED CAP, 1000pF
C620 2113741F25 CAP, 1000pF
C621 2113741F25 CAP, 1000pF
C622 2113741F25 CAP, 1000pF
C623 2113741F25 CAP, 1000pF
C624 2113741F25 CAP, 1000pF
C625 2113741F25 CAP, 1000pF
C626 2113741F25 CAP, 1000pF
C627 2113741F25 CAP, 1000pF
C628 2113741F25 CAP, 1000pF
C629 2113741F25 CAP, 1000pF
C630 2113741F25 CAP, 1000pF
C631 2113741F25 CAP, 1000pF
C632 2113741F25 CAP, 1000pF
C633 2113741F25 CAP, 1000pF
C662 2113741F25 CAP, 1000pF
Circuit
Ref.
Motorola
Part No.
Description
