Motorola Radius CM300 User Manual

3-2 SERVICE AIDS
2.0 Test Equipment
Table 3-2 lists test equipment required to service the radio and other two-way radios.
Table 3-2 Recommended Test Equipment
Motorola Part No. Description Characteristics Application
R2000, R2600,
R2400, or R2001
with trunking
option for Privacy
Plus™ and
Smartnet
Systems™
†
Service Monitor This monitor will
substitute for items
listed below with an
asterisk *
Frequency/deviation meter and
signal generator for wide-range
troubleshooting and alignment
*R1049 Digital Multimeter Two meters recommended for AC/
DC voltage and current
measurements
*S1100 Audio Oscillator 67 to 200Hz tones Used with service monitor for
injection of PL tones
*S1053,
*SKN6009,
*SKN6001
AC Voltmeter,
Power Cable
for meter,
Test leads for meter
• 1 mV to 300 V
• 10 MΩ input
impedance
Audio voltage measurements
R1053 Dual-trace
Oscilloscope
20 MHz bandwidth,
5 mV/cm – 20 V/cm
Waveform measurements
R1443A Broadband
Wattmeter
Transmitter power output
measurements
S1339 RF Millivolt Meter 100 μV to 3 VRF, 10
kHz to 1.2 GHz
RF level measurements
*R1013 SINAD Meter Receiver sensitivity measurements
S1348 (prog) DC Power Supply 0–20 Vdc, 0–20 Amps Bench supply for 13.8Vdc
