Motorola RMU2040 User Manual

RADIO OVERVIEW
English
11
On/Off/Volume Knob
Used to turn the radio ON or OFF and to adjust
the radio’s volume.
Accessory Connector
Used to connect compatible audio accessories.
Model Label
Indicates the model of the radio.
Microphone
Speak clearly into the microphone when sending
a message.
Antenna On all RM Series radios, the antenna is
non-removable
LED In dicator
Used to give battery status, power-up status,
radio call information and scan status.
Side Buttons
Push-to-Talk (PTT) Button
•
Press and hold down this button to talk,
release to leasten it
Side Button 1 (SB1)
•
The Side Button 1 is a general button
that can be configured by the Computer
Programming Software - CPS. The
default setting of SB1 is ‘Monitor’.
Side Button 2 (SB2)
•
The Side Button 2 is a general button
that can be configured by the CPS. The
SB2 default setting is set to scroll until
the desired channel is selected.
RM Series provides a Li-Ion battery. For more
information, see “Battery Feature on Pg.13.

Motorola RMU2040 Specifications

General

Frequency Band	UHF
Frequency Range	450-470 MHz
Channels	4
IP Rating	IP54
Range	Up to 250, 000 sq. ft. / 20 floors
Weight	8.6 oz (with battery)
Dimensions	4.5 x 2.2 x 1.5 in (115.6 x 57.6 x 38.6 mm)
