MSI 800 User Manual

2-4
Install at least one DIMM module into the slots. Memory modules can be
installed into the slots in any order. You can install either single or double-sided
modules to meet your need.
S (Single Side): 64MB ~ 512MB D (Double Side): 128MB ~ 1GB
Combination Slot
1 2
DDR 1
S/D S/D
DDR 2
S/D S/D
Total Memory
64MB~2GB 64MB~2GB
DDR Module Combination
1. The DDR DIMM has only one notch on the center of module. The module will
only fit in the right orientation.
2. Insert the DIMM memory module vertically into the DIMM slot. Then push it in.
3. The plastic clip at each side of the DIMM slot will automatically close.
Volt
notch
Installing DDR Modules
DDR Population Rules
Install at least one DIMM module on the slots. Each DIMM slot supports
up to a maximum size of 1GB. Users can install either single- or double-sided
modules to meet their own needs.
