23
Overview of Components
Overview of Components
SATA4
JSEL1
SATA3
SATA▼1▲2
SATA▼5▲6
CPU_FAN1
PUMP_FAN1
PCI_E1
PCI_E2
PCI_E3
PCI_E4
PCI_E5
PCI_E6
JTPM1
Processor
Socket
CPU_PWR1
JBAT1
M2_2
M2_1
DIMMA1
SYS_FAN1
SYS_FAN3
DIMMA2
DIMMB1
DIMMB2
JUSB3
JUSB2
JUSB1
PWRLED1
JFP1
JFP2
DEMOLED1
JAUD1
SYS_FAN2
JLED1
ATX_PWR1
SYS_FAN4
JUSB4
JCI1
