Chapter 5 Verify the Installation
© National Instruments Corporation 5-3 GPIB-ENET/100 for Windows Me/98/95
Connecting the GPIB Cable
When you finish verifying the installation, you can connect the GPIB cable
to your GPIB-ENET/100.
Note
If you do not have a GPIB cable, as listed in the What You Need to Get Started
section of Chapter 1, Introduction, contact National Instruments for ordering information.
Connect one end of your GPIB cable to your GPIB-ENET/100 and tighten
the thumb screws on the connector. Connect the other end of your GPIB
cable to your GPIB system. Make sure you comply with all IEEE 488.1
cabling restrictions and use only shielded GPIB cables.

National Instruments GPIB Series Specifications

General

Bus Interface	GPIB (IEEE 488)
Operating Systems Supported	Windows, Linux, macOS
Weight	Varies by model
Form Factor	PCI, PCIe, USB
Number of GPIB Ports	1
Software Support	NI-488.2 driver
Compatibility	IEEE 488.1, IEEE 488.2
Connector Type	24-pin IEEE 488 connector
Power Requirements	Varies by model (e.g., USB bus-powered or external power)
Dimensions	Varies by model
Data Transfer Rate	Up to 8 MB/s
