XLTEK Protektor32 Instructions for Use
23
Protektor32 System Configuration
Device styles/models may vary from those shown above.
Legend
Description
Description
A
Stimulator Pods
Medical Grade Power Supply
B
Low Current Stimulator Pods
Isolation Box
C
TCeMEP Pod
PC/Laptop
D
Acquisition Pods
External Triggers
E
Oximeter
Acquisition Head Box
F
Goggles
Stimulator Head Box
G
Cautery Detector
H
Headphones or Ear Inserts
Communication Cable
I
VGA Monitor**
VGA Cable
J
Power Cable (MAINS)
DC Power Cable
K
Isolation Transformer
Power Cable
L
Printer**
USB Data Cable
**VGA monitor and Printer are optional.
Applied Parts include electrodes for EEG and EMG data acquisition, goggles for visual stimulation,
headphones for auditory stimulation, electrical stimulators, and pulse oximeter.
