XLTEK Protektor32 Instructions for Use
57
To run multiple Timelines at the same time:
1. Open the Stimulators Properties window, select Customize... from the Tools menu and click
the Stimulators tab.
2. Select the Enable running multiple timelines and stims option and click OK.
When you run the test, you will now be able to independently start / stop / pause / continue the timelines.
A timeline clock appears when stimulation is paused for a set interval to show when the stimulation will
restart.
For information on the Timebar, Log Book, and the History window features, see the
Reviewing a Study
section.
Impedance Check
The impedance check can be performed at any time during a study. Note that when you check the
impedance, a new Impedance Check note is inserted in the Log Book and on the Timebar.
To perform an Impedance check, follow the steps below:
1. Click the Impedance Check button on the Settings toolbar.
2. Select the impedance Threshold Value.
3. To check a single channel, select the option next to the desired channel.
To check all of the channels, click the Scan All button.
4. To stop the impedance check and return to the test, click the Exit button.
