Specifications | 73
2 kW Radar processor specifications
Processor model AA010012
Processor dimensions Width 5.6" (142 mm)
Height 2.2" (56 mm)
Length 7.9" (200 mm)
Processer weight 1.9 lbs (870 g)
Vibration EN60945
Waterproof No rating
Temperature range +5ºF to +131ºF (–15ºC to +55ºC)
Relative humidity 95% at 104ºF (+40ºC)
Power up time Approximately 35 seconds
DC input 10.8 V to 15 V DC
Power consumption 3 W (when operating)
Leakage current <200 µA (when off, with a remote power input)
12.2 4 kW Specifications
4 kW Scanner specifications
Radar system
Northstar
Simrad
Lowrance
NS-RDR1042MD
DX64s
LRA-2400
Scanner dimensions Width 24.5" (620 mm)
Height 11" (280 mm)
Scanner type Dome
Scanner model AA010025
Scanner weight 22 lbs (10 kg ± 5%)
Vibration Amplitude 0.12" (3 mm) at 0 cpm to 500 cpm
Amplitude 0.03" (0.75 mm) at 500 cpm to 1500 cpm
Amplitude 0.01" (0.2 mm) at 1500 cpm to 3000 cpm
Waterproof IPX6
Scanning mode Raster scanning, PPI
Plane of polarization Horizontal
Preheating time Minimum 90 seconds
Warm-up time Approximately 3 seconds
Power consumption 30 W (maximum) at 24 V DC
DC input 10.8 V to 42 V (DC 12/24/32 V system)
Emission type P0N. Passed JRC FCC/IC/R&TTE Type Certification:
FCC ID: CKENKE249
IC ID: 768C-NKE249
R&TTE: QQ-RTTE-02/03-01
Peak power output 4 kW ± 50% under any pulse condition
Transmitter frequency 9410 ± 30 MHz
Transmitter tube Magnetron NJRC Model MSF1421B
Horizontal beam width 4º ± 10% (-3 dB width)
Vertical beam width 25º ± 20% (-3 dB width)
Side lobe level Below -21 dB maximum (within ± 10º)
Rotation rate 27 rpm ± 10%
