9About the Boiler
1.4 Components
The following diagram shows the key components of the boiler. Component assembly diagrams and particular parts lists are included in the
Appendixes.
Intake Air
Air Filter
Front Panel
Exhaust
Flue Duct
Space Heating
Supply
APS
PCB
Power Switch
Air Vent Connection
LWCO
