Nedap TRANSIT Entry User Manual

TRANSIT ENTRY | INSTALLATION GUIDE
Technical Specifications
26/30
A TECHNICAL SPECIFICATIONS
Item
Specification
Remark
Dimensions 200x220x46.5mm (7.87 x 8.66
x 1.83 inch)
Weight
0.75 kg (1.65 lbs)
Enclosure color
RAL7017 (dark gray)
Enclosure material
Polycarbonate
Chassis material
Aluminum
Cable entry fittings
AGRO Progress MS EMC IP68
4-6mm cable diameter
Recommended wire stripping
length
8 … 10mm
(0.3 … 0.4 inch)
L
Connector K5 0.5mm
2
… 1.5mm
2
(AWG20 … 16)
Springcage type PTSA 1.5
Connector K2,3,4 0.14mm
2
… 0.5mm
2
(AWG24 … 20)
Springcage type PTSA 0.5
Protection class
IP65
Operational temperature
-30°C … +60°C (-22°F … +140°F)
Relative humidity
10 … 93% non-condensing
Identification range
Typical 4 meters (12 feet)
Line-of-sight required
Power supply
12VDC … 24VDC
Current consumption
1A @ 12VDC, 0.5A @ 24VDC
Operating frequency
2.4384GHz … 2.4570GHz
Polarisation
Circular
EIRP
18.7 dBm linear
Immunity EN 301 489-1 V1.6.1
EN 301 489-3 V1.4.1
ERM and EMC
Part 1 and Part 3 common
technical requirements
EN 501130-4: 1995
Alarm systems – Part 4
Safety
EN 60 950-1: 2001 / UL 50
Emission EN 300 440-2 (SRD > 1GHz)
EN 300 330-2 V1.3.1 (SRD < 30 MHz)
FCC part 15.245 (2.4 GHz)
FCC part 15C (120 kHz)
FCC part 15C (13.56 MHz)
Industry Canada RSS210
Shock
IEC 68-2-27 Ea
50 G, 6 ms, 10x3 dir
Bump
IEC 68-2-29 Eb
25 G, 6 ms, 1000x3 dir
Random vibration EN 50155 5 – 150Hz, 5 G, 20
sweeps x 3 dir

Nedap TRANSIT Entry Specifications

General

Brand	Nedap
Model	TRANSIT Entry
Category	Rfid Systems
Language	English
