NETGEAR Orbi RBS50Y User Manual

The user name is admin.The password is the one that you specified the first time that you logged in.
The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select Attached Devices.
The Attached Devices page displays.
5. Select your satellite.
The Edit Device page displays.
6. Make sure that the LED On/Off slider is set to ON.
7. If the LED lighting is turned off, click the LED On/Off slider to turn the LED on.
The top and bottom Light LEDs turn on.
8. Select an LED lighting brightness percentage from the LED Lighting Brightness menu.
9. Click the APPLY button.
Your settings are saved.
Schedule When to Turn On LED Lighting
You can schedule when to turn on the satellite’s LED lighting:
To schedule the LED lighting:
1. Launch a web browser from a computer or mobile device that is connected to your Orbi network.
2. Enter orbilogin.com.
A login window opens.
3. Enter the router admin user name and password.
The user name is admin.The password is the one that you specified the first time that you logged in.
The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select Attached Devices.
The Attached Devices page displays.
5. Select your satellite.
The Edit Device page displays.
6. Make sure that the LED On/Off slider is set to ON.
7. If the LED lighting is turned off, click the LED On/Off slider to turn the LED on.
The top and bottom Light LEDs turn on.
8. Select the Schedule LED Lighting check box.
9. Click the ADD A NEW PERIOD button.
The LED Lighting Schedule page displays.
Manage Your Orbi Outdoor Satellite
21
Orbi Outdoor Satellite

NETGEAR Orbi RBS50Y Specifications

General

Maximum transfer distance	232 m
Antenna type	Internal
Antennas quantity	6
Mounting type	Wall
Product color	White
Output current	2.5 A
Output voltage	12 V
External power adapter	Yes

Weight and Dimensions

Depth	68.58 mm
Width	210.82 mm
Height	269.24 mm
Weight	1387.993 g
