NETGEAR Orbi RBS50Y User Manual

Wall-Mount Your Satellite
To wall-mount your satellite:
1. Use the wall-mount bracket as a template to mark three holes on the wall.
2. Drill holes where you marked on the wall using a 5/32-inch drill bit
3. Place the wall-mount bracket where you drilled the holes and secure the bracket to the wall using the
stucco or concrete screws or the wood screws.
4. Slide the satellite onto the wall-mount bracket.
Overview
8
Orbi Outdoor Satellite

NETGEAR Orbi RBS50Y Specifications

General

Maximum transfer distance	232 m
Antenna type	Internal
Antennas quantity	6
Mounting type	Wall
Product color	White
Output current	2.5 A
Output voltage	12 V
External power adapter	Yes

Weight and Dimensions

Depth	68.58 mm
Width	210.82 mm
Height	269.24 mm
Weight	1387.993 g
