MERCURY 310 Controller
User Guide
The ACBOX 310 is powered by a AC-to-DC power supply with a rechargeable 12V back-up battery. To
open, unlatch the two latches and open cover as shown (FIGURE 1).
The SolarBOX 310 is powered by a solar panel, with internal space for a rechargeable 12V back-up
battery. To open, unlock (if locked), then swing out cover and pull it downward to remove it from the
chassis (FIGURE 2, Left).
Antenna
Pass-Thru
Connector
Gate Control
Button
Cover
Gate Control
Lock
Battery
Transformer
Accessory
Mounting
(behind panel)
Accessory
Mounting
Suggested Battery
Mounting
Mercury 310
Control Board
Mercury 310
Control Board
Latch (x2)
FIGURE 1: ACBOX 310 Features
FIGURE 2: SolarBOX 310 Features
1
2
1.2 SolarBOX 310 Control Box
1.1 ACBOX 310 Control Box
Padlock
Hasp
