Nice SN6021 User Manual

English – 29
STOP Led (red) Cause ACTION
Off Activation of the STOP
input
Check the devices connected to the STOP input
On Everything OK STOP Input active
SbS Led Cause ACTION
Off Activation of the SbS input SbS input not active
On Everything OK This is normal if the device connected to the SbS input is actually active
OPEN Led Cause ACTION
Off Everything OK OPEN input not active
On Activation of the OPEN
input
This is normal if the device connected to the OPEN input is actually active
Table 23 -LED’s on the control unit’s keys
L1 Led Description
Off During normal operation the device indicates “Automatic Closure” is inactive.
On During normal operation the device indicates “Automatic Closure” is active.
Flashing • Function programming in progress
q(EHSk@RGDRSNFDSGDQVHSG+HSLD@MRSG@SHSSGDTRDQLTRSB@QQXNTSSGDCDUHBDQDBNFMHSHNMOG@RD
(refer to Paragraph “6.2 Recognition of the devices”).
L2 Led Description
Off During normal operation the device indicates “Close after photo” is inactive.
On During normal operation the device indicates “Close after photo” is ictive.
Flashing • Function programming in progress
q(EHSk@RGDRSNFDSGDQVHSG+HSLD@MRSG@SHSSGDTRDQLTRSB@QQXNTSSGDCDUHBDQDBNFMHSHNMOG@RDQDEDQ
to Paragraph “6.2 Recognition of the devices”).
L3 Led Description
Off During normal operation the device indicates “Motor Force” for “heavy” doors.
On During normal operation the device indicates “Motor force” for light “doors”
Lampeggia Flashing • Function programming in progress
q(EHSk@RGDRSNFDSGDQVHSG+HSLD@MRSG@SSGDTRDQLTRSB@QQXNTSSGDCNNQNODMHMF@MCBKNRHMFONRHSHNMRQDBN-
gnition phase (refer to Paragraph “6.3 Acquisition of the door opening and closing positions”)
L4 Led Description
Off Durante il funzionamento normale indica “Stand-By” non attivo.
On Durante il funzionamento normale indica “Stand-By” attivo.
Flashing • Function programming in progress
q(EHSk@RGDRSNFDSGDQVHSG+HSLD@MRSG@SHSSGDTRDQLTRSB@QQXNTSSGDKD@EKDMFSGQDBNFMHSHNMOG@RD
(refer to Paragraph “6.3 Acquisition of the door opening and closing positions”)
10
TROUBLESHOOTING
The following table contains instructions to help you solve malfunctions or errors that may occur during the installation stage or in case of failure.
Table 24 - Troubleshooting
Problem Solution
The radio transmitter does not control the door
and the LED on the transmitter does not light up
Check to see if the transmitter batteries are exhausted, if necessary replace them.
The radio transmitter does not control the door
but the LED on the transmitter lights up.
Check the transmitter has been memorised correctly in the radio receiver.
The user is unable to command manoeuvres
and the “BLUEBUS” LED fails to flash.
Check that SPIN is being fed 230V voltage from the power supply. Check to see if F1
and F2fuses have blown. If necessary, identify the reason for the failure and then replace
the fuses with others having the same current rating and characteristics
No manoeuvre starts and the flashing light is off Make sure that the command is actually received. If the command reaches the SbS
input, the corresponding Sbs LED must light up; if you are using the radio transmitter,
the “BlueBus” LED must make two quick flashes.
No manoeuvre starts and the flashing light flashes
a few times
Count the flashes and check the corresponding value in Table 25.
The manoeuvre starts but it is immediately followed
by a short reverse run
The selected force could be too low to move the door.
Check to see whether there are any obstacles; if necessary increase the force
