TECHNICAL CHARACTERISTICS
Nice S.p.a., in order to improve its products, reserves the right to modify their technical characteristics at any time without prior notice. In any
B@RDSGDL@MTE@BSTQDQFT@Q@MSDDRSGDHQETMBSHNM@KHSX@MCjSMDRRENQSGDHMSDMCDCOTQONRDR
All the technical characteristics refer to a room temperature of 20°C (±5°C)
Technical characteristics: SPIN
Model SN6021 SN6031 SN6041
Type Electromechanical gearmotor for the automatic movement of garage doors for residential
use, complete with electronic control unit
Pinion Diameter 9.5mm, 28 teeth; for guides SNA30, SNA30C, SNA6
and guides supplied with SPIN20KCE, SPIN30 and SPIN40
Peak thrust
[corresponds to the force necessary to
start a leaf]
11.7Nm
[650N]
14.4Nm
[800N]
18Nm
[1000N]
Nominal torque
[corresponds to the force necessary to
keep a leaf moving]
5.85Nm
[345N]
7.2Nm
[425N]
9Nm
[560N]
Speed under no load
[corresponding to if “High speed”
is programmed]
106 rpm
[0,20m/s]
The control unit enables programming of 4 speeds equal to approx. 100% - 85% - 70% - 55%
Nominal torque speed
[corresponds to if “High speed”
is programmed]
53 rpm
[0,08m/s]
Maximum frequency of operating cycles 50 cycles per day (the control unit allows up to the maximum described in tables 4 and 5)
Maximum continuous operating time 4 minutes (the control unit limits the continuous operation up to the maximum described in
tables 4 and 5)
Operating limits Normally SPIN can automate sectional or overhead doors which remain within the dimensions
RS@SDCHMS@AKD@MCKHLHSRRODBHjDCHMS@AKDR@MC
SPIN Power supply
SPIN/V1 Power supply
230V
(±10%) 50/60Hz.
120V (±10%) 50/60Hz.
Max. absorbed power 270W 300W 370W
Reduced consumption in Stand-By 4.2W less than 0.8W less than 1.2W
Insulation class 1 (a safety grounding system is required)
Emergency Power Supply With PS124 accessory With PS124 accessory With PS124 accessory
Internal light internal white LED internal white LED internal white LED
FLASH Output If programmed as “SPA “Open door indicator””: output for a maximum 24V-5W lamp;
if programmed as “Flashing light”: output for ELDC or ELB Flashing light (12V, 21W)
if programmed as “Electric lock”: output for maximum 24V- 10W electro-mechanical lock;
if programmed as “Suction cup” output for maximum 24V- 10W electro-mechanical suction cup
Maximum BLUEBUS output load 6 6 6
STOP Input %NQMNQL@KKXNODMBNMS@BSRENQJƄBNMRS@MSQDRHRS@MBDNQMNQL@KKXBKNRDCBNMS@BSR
with self-recognition (any variation from the memorized status causes the “STOP” command
SbS Input For normally open contacts (the closing of the contact causes the SbS command)
Radio AERIAL Input ƄENQ1&NQRHLHK@QSXODNEB@AKD
Radio receiver “SM” connector for SMXI, SMXIS, OXI or OXIT
Programmable functions 4 ON-OFF functions and 4 adjustable functions (see tables 8 and 10)
Recognition functions Recognition of the devices connected up to the BlueBUS output. Recognition of the type of
f23./tCDUHBD-NQL@KKX.ODMNQ-NQL@KKX"KNRDCBNMS@BSNQJƄQDRHRS@MBD
Recognition of the door opening and closing positions and calculation of the slowdown
and partial opening points.
Operating temperature -20°C ÷ 55°C
Use in acid, saline or potentially explosive
atmosphere
No
Protection class IP 40 (use only in indoor or protected environments)
Dimensions / weight 311x327 h 105 / 3,6kg 311x327 h 105 / 4,7kg
