Nikon D4s User Manual

384
U
Image overlay combines two existing NEF (RAW) photographs to
create a single picture that is saved separately from the originals;
the results, which make use of RAW data from the camera image
sensor, are noticeably better than photographs combined in an
imaging application.
The new picture is saved at current image
quality and size settings; before creating an overlay, set image
quality and size (0 90, 94; all options are available).
To create a
NEF (RAW) copy, choose an image quality of NEF (RAW) and an
image size of Large (the overlay will be saved as a large NEF/RAW
image even if Small is selected).
1 Select Image overlay.
Highlight Image overlay in the
retouch menu and press 2.
The
dialog shown at right will be
displayed, with Image 1
highlighted; press J to display
a picture selection dialog listing only large NEF (RAW) images
created with this camera (small NEF/RAW images can not be
selected).
Image Overlay
G button ➜ N retouch menu
+

Nikon D4s Specifications

General

Megapixel	16.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	16.6 MP
Image sensor size	- \
Image formats supported	JPG, RAW, TIF
Maximum image resolution	4928 x 3280 pixels
Image sensor size (W x H)	36 x 23.9 mm
Still image resolution(s)	4928 x 3280, 3696 x 2456, 2464 x 1640, 3200 x 2128, 2400 x 1592, 1600 x 1064, 4096 x 3280, 3072 x 2456, 2048 x 1640, 4096 x 2720, 3072 x 2040, 2048 x 1360
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
ISO sensitivity	200, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Video recording	Yes
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	CF, XQD
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.70 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Mini
Ethernet LAN (RJ-45) ports	1
Scene modes	Portrait, Landscape (scenery)
Photo effects	Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Shade
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FRE, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Power source type	Battery
Battery type	EN-EL18a
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, USB

Weight and Dimensions

Depth	90.5 mm
Width	160 mm
Height	156.5 mm
Weight	1180 g
