Nikon D4s User Manual

24
s
Insert the Battery
1 Turn the camera off.
2 Remove the battery-chamber cover.
Lift the battery-chamber cover latch, turn
it to the open (
A ) position ( q ) and remove
the BL-6 battery-chamber cover (
w ).
3 Attach the cover to the battery.
If the battery release is positioned so that
the arrow (4) is visible, slide the battery
release to cover the arrow.
Insert the two
projections on the battery into the
matching slots in the cover and slide the
battery release to completely reveal the
arrow.
D Inserting and Removing
Batteries
Always turn the camera off
before inserting or removing
batteries.
D The BL-6 Battery-Chamber Cover
The battery can be charged with the BL-6 attached.
To prevent dust
from accumulating inside the battery chamber when the battery is not
inserted, slide the battery release in the direction indicated by the arrow
(4), remove the BL-6 from the battery, and replace it on the camera.
Other battery covers can not be used with this camera.

Nikon D4s Specifications

General

Megapixel	16.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	16.6 MP
Image sensor size	- \
Image formats supported	JPG, RAW, TIF
Maximum image resolution	4928 x 3280 pixels
Image sensor size (W x H)	36 x 23.9 mm
Still image resolution(s)	4928 x 3280, 3696 x 2456, 2464 x 1640, 3200 x 2128, 2400 x 1592, 1600 x 1064, 4096 x 3280, 3072 x 2456, 2048 x 1640, 4096 x 2720, 3072 x 2040, 2048 x 1360
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
ISO sensitivity	200, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Video recording	Yes
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	CF, XQD
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.70 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Mini
Ethernet LAN (RJ-45) ports	1
Scene modes	Portrait, Landscape (scenery)
Photo effects	Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Shade
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FRE, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Power source type	Battery
Battery type	EN-EL18a
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, USB

Weight and Dimensions

Depth	90.5 mm
Width	160 mm
Height	156.5 mm
Weight	1180 g
