Nikon D4s User Manual

424
n
Replacing the Clock Battery
The camera clock is powered by a CR1616 lithium battery with a life
of about two years.
If the B icon is displayed in the top control
panel while the standby timer is on, the battery is running low and
needs to be replaced.
When the battery is exhausted, the B icon
will flash while the standby timer is on.
Photographs can still be
taken but will not be stamped with the correct time and date.
Replace the battery as described below.
1 Remove the main battery.
The clock battery chamber is located on the roof of the main
battery chamber.
Turn the camera off and remove the
EN-EL18a battery.
2 Open the clock battery chamber.
Slide the clock battery chamber cover
toward the front of the main battery
chamber.
3 Remove the clock battery.
4 Insert the replacement battery.
Insert a new CR1616 lithium battery so
that the positive side (the side marked
with “+” and the battery name) is visible.

Nikon D4s Specifications

General

Megapixel	16.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	16.6 MP
Image sensor size	- \
Image formats supported	JPG, RAW, TIF
Maximum image resolution	4928 x 3280 pixels
Image sensor size (W x H)	36 x 23.9 mm
Still image resolution(s)	4928 x 3280, 3696 x 2456, 2464 x 1640, 3200 x 2128, 2400 x 1592, 1600 x 1064, 4096 x 3280, 3072 x 2456, 2048 x 1640, 4096 x 2720, 3072 x 2040, 2048 x 1360
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
ISO sensitivity	200, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Video recording	Yes
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	CF, XQD
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.70 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Mini
Ethernet LAN (RJ-45) ports	1
Scene modes	Portrait, Landscape (scenery)
Photo effects	Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Shade
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FRE, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Power source type	Battery
Battery type	EN-EL18a
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, USB

Weight and Dimensions

Depth	90.5 mm
Width	160 mm
Height	156.5 mm
Weight	1180 g
