Nikon D4s User Manual

65
y
6 Start recording.
Press the movie-record button to start
recording.
A recording indicator and the
time available are displayed in the
monitor.
Exposure is set using matrix
metering and can be locked by pressing
the center of the sub-selector (0 136) or
altered by up to ±3 EV using exposure
compensation (0 138).
In autofocus
mode, the camera can be refocused by
pressing the AF-ON button.
A Audio
The camera can record both video and sound; do not cover the
microphone on the front of the camera during movie recording.
Note that the built-in microphone may record sounds made by the
lens during autofocus, vibration reduction, or changes to aperture.
A See Also
Frame size, frame rate, microphone sensitivity, card slot, and ISO
sensitivity options are available in the Movie settings menu
(0 74). Focus can be adjusted manually as described on page 59.
The roles played by the center of the multi selector, the Fn and Pv
buttons, and the center of the sub-selector can be chosen using
Custom Settings f1 (Multi selector center button; 0 335), g1
(Assign Fn button; 0 353), g2 (Assign preview button; 0 355),
and g3 (Assign sub-selector center; 0 356), respectively.
Custom
Setting g4 (Assign shutter button; 0 357) controls whether the
shutter-release button can be used to start movie live view, or to
start and end movie recording, or (when pressed all the way down)
to take photographs during movie recording.
For information on
preventing unintended operation of the a button, see Custom
Setting f17 (Live view button options; 0 349). See page 169 for
information on measuring a value for preset white balance during
live view photography and movie live view.
Movie-record button
Recording indicator
Time remaining

Nikon D4s Specifications

General

Megapixel	16.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	16.6 MP
Image sensor size	- \
Image formats supported	JPG, RAW, TIF
Maximum image resolution	4928 x 3280 pixels
Image sensor size (W x H)	36 x 23.9 mm
Still image resolution(s)	4928 x 3280, 3696 x 2456, 2464 x 1640, 3200 x 2128, 2400 x 1592, 1600 x 1064, 4096 x 3280, 3072 x 2456, 2048 x 1640, 4096 x 2720, 3072 x 2040, 2048 x 1360
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
ISO sensitivity	200, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Video recording	Yes
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	CF, XQD
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.70 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Mini
Ethernet LAN (RJ-45) ports	1
Scene modes	Portrait, Landscape (scenery)
Photo effects	Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Shade
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FRE, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Power source type	Battery
Battery type	EN-EL18a
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, USB

Weight and Dimensions

Depth	90.5 mm
Width	160 mm
Height	156.5 mm
Weight	1180 g
