INSTRUCTIONS FOR USE
9096910000(1)2006-09 29
DETERGENT TANK CLEANING
(For X20D, X20C, X24D)
Clean the detergent tank (45) according to the following procedure:
1. Drive the machine to the appointed disposal area.
2. Open the cover (22) and check that the recovery water tank (21) is empty, otherwise empty it with the drain hose (16).
Close the cover (22).
3. Grasp the handle (41) and carefully lift the tank (40).
4. Unscrew the plug and disconnect the hose (48) from the tank (45).
5. Remove the tank by releasing it from the retainers.
6. Wash the tank in the appointed disposal area.
7. Install the tank (45) and connect it to the hose (48).
8. When the detergent tank has been drained, the AXP must be drained too (see the procedure in the following paragraph).
AXP DRAINING
(For X20D, X20C, X24D)
1. Clean the detergent tank according to the procedure shown in the previous paragraph. To remove the detergent remained
in the hoses and in the pump, perform the following procedure.
2. Grasp the handle (41) and carefully lower the tank (40).
3. Turn on the machine by turning the ignition key (80) to “I” position.
4. Turn on the AXP by pressing the switch (77). Check that the switch warning light (78) turns on.
5. Simultaneously press the switches (77 and 82a), until the switch warning light (78) starts flashing (after about 5 seconds).
6. Release the switches and wait for the warning light (78) to stop flashing and for the vacuum system to turn on.
7. Collect the detergent remained on the floor.
8. Turn the ignition key (80) to “0” position.
9. Grasp the handle (41) and carefully lift the tank (40), then check that the hose (48) is empty, otherwise perform the steps
3 to 9 again.
NOTE
The drain cycle lasts about 30 seconds; then the vacuum function automatically activates to eliminate all
solution traces.
The draining cycle can also be performed with the detergent tank (45) full of water, thus cleaning the system
thoroughly.
It is advisable to perform the draining cycle when the AXP is really dirty/encrusted because the machine has
not been used/cleaned for a long time.
The draining cycle can be performed also to quickly fill the detergent hose when the tank (45) is full but the
system is still empty.
If necessary, the discharge can be repeatedly performed.
