ELECTRICAL SYSTEM
ENGLISH
SERVICE MANUAL
44
9097091000(1)2007-06 Micromatic
TM
M17B - Micromatic
TM
M17E
COMPONENT LOCATION [MICROMATIC M17E]
EV1: Solenoid valve
FR: Frame
M1: Brush/pad motor
M2: Vacuum system motor
PL: Plug
SW1: Brush/pad switch
SW2: Vacuum switch
SW1
SW2
PL
EV1
M2-C1
M1
S301228
