ELECTRICAL SYSTEM
SERVICE MANUAL
ENGLISH
Micromatic
TM
M17B - Micromatic
TM
M17E 9097091000(1)2007-06
45
WIRING DIAGRAM [MICROMATIC M17B] (for machines before 2007/05)
Key:
CH1: Battery charger
C1: Battery charger connector
EB1: Electronic board
EB2: Electronic board LED (CF BALED)
ES1: Brush switch
ES2: Vacuum switch
ES3: Battery charger realay
EV1: Water solenoid valve
F1: Brush fuse (40A)
F2: Vacuum system fuse (30A)
F3: Solenoid valve and electronic board fuse (5A)
IS1: Negative insulator
M1: Brush/pad motor
M2: Vacuum system motor
SW1: Brush/pad switch
SW2: Vacuum switch
Colour code
BK: Black
BU: Blue
BN: Brown
GN: Green
GY: Grey
OG: Orange
PK: Pink
RD: Red
VT: Violet
WH: White
YE: Yellow
