Nilfisk-Advance SC500 User Manual

INSTRUCTIONS FOR USE ENGLISH
9099974000 - SC500 9
11/2014
revised 07/2017
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specic use:
– GEL batteries
– Electronic battery charger
– Brushes of different materials
– Pads of different materials
– Splash guard
– Natural rubber squeegee blades
– EcoFlex
– USB port
For further information concerning the optional accessories, contact an authorised Retailer.
TECHNICAL DATA
Model
Nilsk
SC500 53 B
Nilsk
SC500 53R B
Solution tank capacity 45 litres
Recovery tank capacity 45 litres
Machine length 1,277 mm 1,302 mm
Machine width with squeegee 720 mm
Machine width without squeegee 532 mm 538 mm
Machine height 1,063 mm
Cleaning width 530 mm
Driving wheel diameter 200 mm
Driving wheel specic pressure on the oor 0.7 N/mm
2
Rear wheel diameter 80 mm
Rear wheel specic pressure on the oor 2.1 N/mm
2
Brush/pad diameter 530/508 mm
Brush pressure with extra pressure function turned off 15 kg 22 kg
Brush pressure with extra pressure function turned on 30 kg 30 kg
Solution ow values
0.75 cl/m / 1.5 cl/m
3.0 cl/m / 2.8 l/min
0.38 cl/m / 0.75 cl/m
1.5 cl/m / 2.8 l/min
EcoFlex system detergent percentage 0.25 % ÷ 3 %
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 63 ± 3 dB(A) 65 ± 3 dB(A)
Sound pressure level at workstation in silent mode (LpA) 60 ± 3 dB(A) 61 ± 3 dB(A)
Machine sound power level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 81 dB(A) 83 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 2.5 m/s
2
Maximum gradient when working 2 %
Drive system motor power 200 W
Drive speed (variable) 0 - 5 km/h
Vacuum system motor power 280 W
Vacuum system circuit capacity 760 mm H
2
O
Brush motor power 450 W 670 W
Brush rotation speed 155 rpm -
Total absorbed power (*) 500 W
IP protection class X4
Protection class (electric) III (I for the battery charger)
Battery compartment size 350x350x260 mm
System voltage 24 V
Standard batteries (2) 12 V 105 AhC5
Battery charger 24 V 13 A
Work autonomy (*) 3.5 hour
Weight without batteries and with empty tanks
83 kg
85 kg (full package)
88 kg
Gross vehicle weight (GVW) 207 kg 210 kg
Shipping weight
114 kg
192 kg (full package)
119 kg
(*) Values reect standard operating conditions (EN 60335-2-72)
