Mechanical spare parts list
ITEM/CIRCUIT REF. QTY PART NAME
I001 1 A-COVER
I002 1 KEYMAT S60
I003 2 SCREWS M1.6 X 4.5 T6+
I004 2 SCREWS M1.6 X 4.5 T6+ SILVER
A1 1 UI-KEYMAT PWB S60 ASSY (I005 -I007)
I005 1 UI PWB
I006 4 LEDS
I007 1 DOMESHEET
I008 6 SCREW M1.8x6.0 REMFORM T6+
I009 1 LCD AM 352x416 COG 256kCO Keyno
A2 1 SLIDE ASSY (A3 + A4 + A5)
A3 1 UI FRAME ASSY (I010 - I013 + A4)
I010 1 UI SUPPORT
I011 2 SCREWS M1.6 X 4.5 T6+ SILVER
I012 1 EARPIECE + SPRING
I013 1 CAMERA VGA (FRONT)
I014 1 UI FRAME SPARE
A4 1 1MJ UI PWB ASSY (I014 & I301 - I305)
I015 1 1MJ UI PWB
I301 1 IRDA
I302 1 CAMERA SOCKET
I303 1 LCD CONNECTOR
I304 1 FLEXI CONNECTOR
I305 1 BOARD TO BOARD CONNECTOR
A5 1 ENGINE SHIELD ASSY (I101 - I103)
I101 1 ENGINE SLIDE SHIELD
I102 1 SLIDE SPRING
I103 2 SLIDE METAL RUNNER
I104 1 FLEX I/CONN MODULE
I105 1 KEYMAT BEZEL
I106 1 ITU KEYMAT
RM-91; RM-92
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –7
Copyright © 2006 Nokia. All rights reserved.
