RM-91 component parts lists and layouts
Component parts list 1ME_09a
Item Side Grid ref. Type Description and value
A4000 Top E 10
MIRO_BT_SHIE
LD_9590738
SHIELD R1113
BLUETOOTH ~ ~
A7000 Top F 16
MIRO_RF_SHIE
LD_0264194
SHIELD R1113 RF
ASSY ~ ~
A7003 Bottom E 16
MIRO_PWR_SH
IELD_9590739
SHIELD R1113
POWER SUPPLY ~ ~
A7005 Bottom H 8
MIRO_BB_SHIE
LD_0264195
SHIELD R1113 BB
ASSY ~ ~
B2200 Bottom G 8
CRYSTAL_3.3X
1.6_H0.9
CRYSTAL
32.768KHZ
+-20PPM 12.5PF 32.768kHz ~
C1100 Bottom I 14 0402C Chipcap 5% NP0 10p 50V
C1101 Bottom I 13 0402C_H0.6
CHIPCAP X5R 100N
M 16V 0402 100n 16V
C1103 Bottom G 14 0402C Chipcap 5% NP0 10p 50V
C1104 Bottom H 13 0402C Chipcap 5% NP0 10p 50V
C1105 Bottom H 11 0402C
Chipcap X7R 10%
50V 0402 1n0 50V
C1109 Bottom H 11 0402C
Chipcap X7R 10%
50V 0402 1n0 50V
C2005 Bottom F 2 0402C
Chipcap X7R 10%
16V 0402 10n 16V
C2006 Bottom F 2 0402C
Chipcap X7R 10%
16V 0402 10n 16V
C2007 Bottom H 2 0402C Chipcap 5% NP0 10p 50V
C2008 Bottom H 2 0402C Chipcap 5% NP0 10p 50V
C2009 Bottom H 2 0402C Chipcap 5% NP0 10p 50V
C2010 Bottom H 2 0402C Chipcap 5% NP0 10p 50V
C2012 Bottom C 2 0603C_H0.95
CHIPCAP X5R 1U K
25V 0603 1u0 25V
C2106 Bottom I 7 0402C Chipcap 5% NP0 56p 50V
C2107 Bottom I 7 0402C Chipcap 5% NP0 56p 50V
C2108 Bottom H 7 0402C Chipcap 5% NP0 15p 50V
C2109 Bottom H 7 0402C Chipcap 5% NP0 15p 50V
C2110 Bottom J 14 0402C Chipcap 5% NP0 56p 50V
RM-91; RM-92
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –9
Copyright © 2006 Nokia. All rights reserved.
