Keyboards
The device keyboard is split between the main ITU 3x4 keyboard located on the engine board and the
remainder of the keyboard located on the S60 UI board on the other side of the slide module. All the keys
are located as part of the same matrix, and are connected directly to the APE ASIC in the case of the keys on
the engine PWB, and through ASIPs in the case of the keys on the S60 PWB.
Key matrix assignments:
Key Row Column Switch reference
0 6 0 S4413
1 3 2 S4407
2 2 1 S4404
3 2 2 S4403
4 5 3 S4412
5 3 0 S4408
6 3 3 S4406
7 2 0 S4405
8 2 3 S4414
9 4 0 S4411
* 4 1 S4410
# 4 3 S4409
END 5 0 U13
SEND 1 1 U4
CLEAR 6 2 U2
APPS 6 3 U12
EDIT 6 1 U3
Operator/Media 5 2 U1
NAVI left 0 2 S1
NAVI right 0 3 S1
NAVI up 1 2 S1
NAVI down 1 3 S1
NAVI select 1 0 S1
Left Soft Key 0 0 U10
Right Soft Key 0 1 U8
Camera 4 2 S4402
RM-91; RM-92
Nokia Customer Care System Module
Page 9 –18 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
