RM-92 component parts lists and layouts
Component parts list 1NN_07a
Item Side Grid ref. Type Description and value
A4000 Top E 10
MIRO_BT_SHIELD
_9590738
SHIELD R1113
BLUETOOTH ~ ~
A7000 Top E 16
MIRO_RF_SHIELD
_0264194 SHIELD R1113 RF ASSY ~ ~
A7003 Bot E 16
MIRO_PWR_SHIE
LD_9590739
SHIELD R1113 POWER
SUPPLY ~ ~
A7005 Bot G 8
MIRO_BB_SHIELD
_0264195 SHIELD R1113 BB ASSY ~ ~
B2200 Bot G 8
CRYSTAL_3.3X1.6
_H0.9
CRYSTAL 32.768KHZ
+-20PPM 12.5PF 32.768kHz ~
C1100 Bot H 14 0402C Chipcap 5% NP0 10p 50V
C1101 Bot H 13 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C1103 Bot G 13 0402C Chipcap 5% NP0 10p 50V
C1104 Bot G 13 0402C Chipcap 5% NP0 10p 50V
C1105 Bot G 11 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C1109 Bot H 11 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2005 Bot F 2 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2006 Bot F 2 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2007 Bot H 2 0402C Chipcap 5% NP0 10p 50V
C2008 Bot H 2 0402C Chipcap 5% NP0 10p 50V
C2009 Bot G 2 0402C Chipcap 5% NP0 10p 50V
C2010 Bot G 2 0402C Chipcap 5% NP0 10p 50V
C2012 Bot C 2 0603C_H0.95
CHIPCAP X5R 1U K 25V
0603 1u0 25V
C2106 Bot I 7 0402C Chipcap 5% NP0 56p 50V
C2107 Bot H 7 0402C Chipcap 5% NP0 56p 50V
C2108 Bot G 7 0402C Chipcap 5% NP0 15p 50V
C2109 Bot H 7 0402C Chipcap 5% NP0 15p 50V
C2110 Bot I 14 0402C Chipcap 5% NP0 56p 50V
C2111 Bot I 13 0402C Chipcap 5% NP0 56p 50V
RM-91; RM-92
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –35
Copyright © 2006 Nokia. All rights reserved.
