Item Side Grid ref. Type Description and value
C2113 Bot I 14 0402C Chipcap 5% NP0 56p 50V
C2114 Bot I 14 0402C Chipcap 5% NP0 56p 50V
C2115 Bot H 14 0402C Chipcap 5% NP0 56p 50V
C2202 Bot G 7 0402C
Chipcap X5R 10% 6.3V
0402 220n 6.3V
C2203 Bot H 8 0603C
CHIPCAP X5R 4U7 K 6V3
0603 4u7 6.3V
C2204 Bot H 7 0603C
CHIPCAP X5R 4U7 K 6V3
0603 4u7 6.3V
C2205 Bot G 7 0402C
Chipcap X5R 10% 6.3V
0402 220n 6.3V
C2206 Bot F 7 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2211 Bot H 8 0603C
CHIPCAP X5R 4U7 K 6V3
0603 4u7 6.3V
C2213 Bot G 8 0405_GNM23
CHIP ARRAY X5R 2X1U K
6V3 MA 0405 2x1u 6.3V
C2215 Bot G 8 0405_GNM23
CHIP ARRAY X5R 2X1U K
6V3 MA 0405 2x1u 6.3V
C2217 Bot G 7 0402C
CHIPCAP X5R 1U5 K 4V
0402 1u5 4V
C2220 Bot H 8 0405_GNM23
CHIP ARRAY X5R 2X1U K
6V3 MA 0405 2x1u 6.3V
C2222 Bot H 8 0405_GNM23
CHIP ARRAY X5R 2X1U K
6V3 MA 0405 2x1u 6.3V
C2226 Bot G 8 0402C
CHIPCAP X5R 1U5 K 4V
0402 1u5 4V
C2228 Bot H 8 0405_GNM23
CHIP ARRAY X5R 2X1U K
6V3 MA 0405 2x1u 6.3V
C2301 Bot F 9 0805C
CHIPCAP X5R 22U M 6V3
0805 22u 6V3
C2302 Bot H 9 0805C
CHIPCAP X5R 22U M 6V3
0805 22u 6V3
C2304 Bot H 10 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C2312 Bot F 8 0402C
CHIPCAP X5R 1U K 6V3
0402 1u0 6.3V
C2314 Bot G 10 0805C
CHIPCAP X5R 4U7 M 25V
0805 4u7 25V
C2316 Bot G 9 0402C
CHIPCAP X5R 1U5 K 4V
0402 1u5 4V
RM-91; RM-92
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –36 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
