Nortec NHPC User Manual

39 | Start Up
NHTC/PC Pre-Start Up Checklist
Unit Serial #: _________________ Tag: _______________
Unit type: _______ __________ Voltage: ________V/_____ph Steam output: ______lb/hr
Cylinder type: Customer/Job: Address:
Water Quality:
 Well water  City water  Softened water 
Humidifier Mounting: (Clearances around the unit Acceptable Obstruction)
 Level  Front/Side Clearance 
Steam Line(s):
 Slope up (min 2 in/ft).  Slope down (min 0.500 in/ft) 
 Diameter / Size Material
 Low point condensate traps  No Hose Kinks / Restrictions 
 Type of Insulation
Condensate Line(s):
 P Trap min 6 in or duct press + 2in  P Trap min 12 in drop 
Water Line:
 1/2 in to within 4ft of unit  Water pressure: 30-80 psig 
Drain Line:
 Air gap within 3 ft of the unit  Diameter / Size
Cylinder:
 Seated in drain valve and secured yes  no 
Wiring:
 Wiring connections and connectors secured yes  no 
Controls:
 Control Location Control to Terminal 4 
 High Limit Location High Limit to terminal 5 
Power:
 Voltage, amp, fuse per Spec Label: yes  no 
 Disconnect switch located close to humidifier yes  no 
 Panel Number
Inspected by: Date of inspection: ______/_______/______
Company:
