Nortec NHPC User Manual

47 | Operation
NHTC Humidifier Configuration
Navigating the NHTC Software
The four input buttons below the digital display are used to navigate in the NHTC’s software and
to enter values. The function of the four buttons changes depending on what is being displayed
on the screen. In all cases 4 icons representing the functions of the buttons are shown at the
bottom of the screen.
Figure 39: Navigating the NHTC/PC Software
Main Menu (NHTC Password)
The menu levels of the NHTCare password protected to prevent configuration changes by
unauthorized persons. In order to access the menu level press the button corresponding to the
Menu icon and when prompted enter the password 0335.
Enter Password
Press the Menu button from any
status screen. Enter the user
level code 0335 using the up
arrow to change the value of each
digit and the right arrow to move
to the next digit. Press the Set
button.
Main Menu
From here you can access all user
configurable settings. Select any
sub-menu by using the up/down
arrow buttons and pressing Set
when the desired one is
highlighted.
Note: Do not make changes
unless you are familiar with the
software.
Request – 100%
Idle 30 lb/hr
04/30/09 14:25:22
Security loop : Closed
Menu ?/A/B
Set P
45%
45 %
ESC Set
45%
Screen Displays
Screen Displays
Press to go
down a
menu level
Press to
go left
/right one
screen
?=Press for
information
Press to go
up a menu
level
Press to
increase/
decrease
value
Press to
accept
setting and
go up a
level
A or B = cylinder
of double unit,
press to display
other cylinders info.
