Supervisory Signal 3. Operating Modes
AFP-300/AFP-400 Operations PN 50260:C1 05/22/97 7
Supervisory Signal
Note: You can program
Supervisory signals as Tracking
or Latching.
Supervisory signals cause the control panel to do the following:
• Produce a warbling audible tone;
• Turn on the Supervisory relay (MPS-400, TB5) and flash the Supervisory LED;
• Display “Active” in the status banner on the control panel; and
• Turn off the panel sounder for all Silenced alarms.
Figure 7 Typical Supervisory Signal Display
Non-Alarm Point Operation
Non-Alarm points are MMX addressable modules that activate Control-by-Event.
These points do not activate the System Alarm LED or the panel sounder. Non-Alarm
points use three type codes: Non-Fire, Hazard Alert, and Fire Control.
Table 3 Non-Alarm Points
Trouble Monitor Point Operation
Trouble Monitor-type MMX modules monitor remote power supplies or other external
equipment. These types of MMX modules operate like troubles—but with the
following differences:
• The LCD display status banner displays “Active”;
• The type code is “Trouble Mon”;
• The modules latch—until the troubles are returned to normal condition and an
operator resets the control panel; and
• MMX modules can have Control-by-Event.
Type Code Does this... Used for...
Non-fire
(Tracking)
Activates Control-by-Event only. Energy management or other
non-fire situations.
Hazard Alert
(Latched)
Sends a message to the LCD display,
history file, printer, and LCD-80
(status – Active), and overrides code
selection for NACs, regardless of the
zone F8 coding selection.
Monitoring critical processes or
other hazardous situations, such
as a tornado.
Fire Control
(Tracking)
Sends messages to the LCD, history
file, printer and LCD-80.
Air handler shutdown, intended
to override automatic fire
functions.
ACTIVE TAMPER I.C.U. WEST WING
VISITORS LOUNGE 11:55PM TUE 02/11/97
Status banner ACTIVE
