4. Read Status Read Status Options
16 AFP-300/AFP-400 Operations PN 50260:C1 05/22/97
Read Status for Points
and Zones
Read Point options let you display point and zone status on the display, but the
information is not sent to the serial ports or the history file. To read the status of points
and zones, press <0> then <Enter> from the Read Status screen. The control panel
displays the Read Point screen (Figure 11):
Figure 11 Read Point Screen
• To read a detector, press H then enter the detector address.
• To read a module, press
I then enter the module address.
• To read an output circuit, press
J then enter the output circuit address.
Read Status for a
Detector, Module, or
Output
From the Read Status screen, press
0; then press <Enter>. You can then read the
status of a detector, module, or output. For example, to read the status of a detector at
D101, press
H, enter the address (D101), then press <Enter>. The control panel
displays information about the detector as shown in Figure 12:
Figure 12 Detector Read Status Sample Screen
ZONE=Z,AA,E DETECTORS=*,AAA,E
MODULE=#,AAA,E OUTPUT CKT=&,A-A,E
NORMAL SMOKE (PHOTO) DETECTOR ADDR 101
Z03 Z Z Z Z 000%AL:5 PA:0 *V D101
Multidetector selection
Type Code
Alarm Verification selection
Custom Label for the detector
Default Zone
Selection
Alarm Sensitivity Level
Pre-Alarm Sensitivity Level
Address (01-99)
D (Detector) or M (Module
or Output
SLC loop number
