page 21
TROUBLESHOOTING GUIDE
Read before calling Service Center
Trouble Possible Cause Possible Remedy
1. Loss or decrease
of vacuum occurs.
1a. Debris pail is completely full. 1a. Empty debris pail as described on
page 3 of the Homeowners Guide.
1b. Obstruction in the hose. A blockage in the hose
can be determined by inserting the hose into any
wall inlet and, while power unit is running, check
each additional inlet for normal suction by holding
the palm of your hand over the open inlet. If normal
suction is felt at all other inlets, insert the hose
into a second inlet. If the blockage still exists it is
located in the hose. However, if the blockage
does not occur when the hose is changed, the
blockage is probably located in the tubing
system leading to the original inlet.
1b.Insert handle end of hose into utility
valve at power unit. Turn unit on. This
will reverse normal air flow through the
hose and dislodge any clogs.
1c. Obstruction in the tubing system inside the
walls.
1c. Insert hose end into any inlet with power
unit running, place the palm of your hand
over the opposite end of the hose. When
you can feel the suction increase, hold
your hand over the hose end for a few
seconds and then quickly remove your
hand. This procedure repeated several
times should clear the obstruction. If the
blockage is not cleared, contact your
nearest Service Center.
1d. Wall inlet cover not properly sealed. 1d. Check all wall inlet covers to be sure
they are closed and sealed tightly.
1e. Exhaust tubing or vent clogged. 1e. Inspect and remove any blockages.
2. Power unit does not
start, or shuts off during
normal operation with
no LED showing red
or illuminated.
2a. Defective inlet. Check other wall inlets. 2a. Replace defective wall inlet.
2b. Thermoprotector has been activated OR there is
a tripped circuit breaker on the unit.
2b. Turn unit off for 20 minutes then plug
unit back in. If unit does not start, look
for the tripped circuit breaker behind
the unit, a white button has popped up,
push it back to reset it. If circuit breaker
trips again, unplug your unit and contact
your local Service Center.
2c. Blown fuse or tripped circuit breaker on house
electrical panel.
2c. Replace fuse or reset circuit breaker on
wall panel.
2d. Defective hose. 2d. Replace hose as required.
2e. Microprocessor Lockup. Note: This would apply
only to Broan VX6000C & VX12000C and
NuTone VX550CC & VX1040CC.
2e. 1) Push Reset button while unit is
engaged OR
2) Unplug unit completely for 60 seconds.
2f. Low line voltage. 2f. Contact your local electricity distributor.
2g. Debris pail full sensing has been activated. 2g. Empty debris pail as described in
Homeowners Guide.
3. Power unit fails to stop
when the hose is
removed.
3a. An electrical short has occurred somewhere in
the system.
3a. A complete check of all wall inlets and power
unit low voltage control lead connections.
Turn system off by removing fuse or
tripping circuit breaker at house fuse box.
4. For Broan VX6000C &
VX12000C and NuTone
VX550CC & VX1040CC.
All lights on control
panel flash when unit
is first plugged in.
4a. Two or more hoses may be plugged into
the system.
4a. Check all other wall inlets, utility valve
at power unit and sweep inlet valve
.
To Next Page
