Jetson Orin NX Series and Jetson Orin Nano Series DG-10931-001_v1.1 | 79
Chapter 15. Design and Bring-Up
Checklists
The design checklist is intended to help ensure that the correct connections have been made
in a design. The check items describe connections for the various interfaces and the
check item description, is different, or is not applicable to the design. The bring-up checklist is
intended to provide basic items to check during bring-up for power delivery and the various
interfaces used in a design.
To access the attached files, click the Attachment icon on the left-hand toolbar on this PDF
(using Adobe Acrobat Reader or Adobe Acrobat). Select the file and use the Tool Bar options
(Open, Save) to retrieve the documents. Excel files with the .nvxlsx extension will need to be
renamed to .xlsx to open.

Nvidia Jetson Orin Nano Series Specifications

General

Memory	8 GB 128-bit LPDDR5
AI Performance	40 TOPS (INT8)
Operating Temperature	-25°C to 80°C
Module Size	69.6 mm x 45 mm
GPU	NVIDIA Ampere architecture with 512 CUDA cores and 16 Tensor Cores
CPU	6-core Arm Cortex-A78AE v8.2 64-bit CPU
Storage	16GB eMMC 5.1
Connectivity	Gigabit Ethernet
Other I/O	I2C, SPI, UART
Operating System Support	Ubuntu
CSI Camera	2x MIPI CSI-2
