Direction Description and OPN Designation
Connector side inlet to power side outlet. The airflow direction is indicated
by red latches or by red dots that are placed on the power inlet side.
OPN designation is “-R”.
Power side inlet to connector side outlet. The airflow direction is indicated
by blue latches or by blue dots that are placed on the power inlet side.
OPN designation is “-F”.
Package Contents
Before installing your new system, unpack it and check against the parts list below that all the parts
have been sent. Check the parts for visible damage that may have occurred during shipping.
The SN2700 and SN2410 package content is as follows:
1 – System
1 – Rail kit
1 – Power cable for each power supply unit – Type C13-C14
1 – Cable retainer for each power supply unit
1 – DB9 to RJ-45 2m harness
1 - RJ-45 to RJ-452m harness
The SN2100/SN2010 package content is as follows:
1 – System
1 – Power cable for each power supply unit – Type C13-C14
1 – DB9 to RJ-45 2m harness
The SN2201 package content is as follows:
1 – System
1 – Rail kit
1 – Power cable for each power supply unit – Type C13-C14
1 – DB9 to RJ-45 2m harness
1 - RJ-45 to RJ-452m harness
A designated rail kit for the SN2100/SN2010 systems can be purchased separately.
