- 84 -
6. Troubleshooting
3
Check for jammed paper in the duplex unit. If jammed paper remains, pull it
out gently. Check the back side of the duplex unit and remove jammed paper
gently if it remains.
4
Open the upper duplex unit cover (2) and check for jammed paper. If jammed
paper remains, pull it out gently and close the cover.
5
Replace the duplex unit (1) into the machine.
Task is complete.
A paper jam has occurred around the front cover.
1
Insert your finger into the recess on the right side of the machine and pull the
front cover open lever (1) to open the front cover (2) forward.
2
Remove the jammed paper gently in the direction of the arrow if an edge of
jammed paper can be seen, and then go to step 8. If you cannot find jammed
paper, go to step 3.
Error Code "372"
To Next Page
