Oki MB460 User Manual

MFP overview > 13
R EAR VIEW
12. Control panel
With LCD and operator buttons.
One touch key (shown) is only for MB470/MB480. Refer to “Control panel” on page 14.
REF. DESCRIPTION
13. Access panel
Allows access to install optional memory.
14. Duplex unit
Provides automatic two-sided printing.
15. Rear output cover (closed) (face up stacker)
This is mainly used for heavy print media. When used in conjunction with the multi purpose
feed tray, the paper path through the MFP is essentially straight. This avoids bending the paper
around curves in the paper path.
16. AC power socket
17. Parallel connector
18. USB connector
19. Test switch
20. Network connection
21. Line connection (MB470/MB480)
Socket for connecting the machine to the telephone line.
Tel connection (MB470/MB480)
Socket for connecting a telephone handset (if required).
REF. DESCRIPTION
13
15
14
16
21
17
18
19
20
