24
EN
Using the wide panel
Use the built-in wide panel in flash shooting when the lens focal length
is set to a position wider than 12 mm.
1 When the lens focal length is shorter
than 12 mm (24 mm with the 135 type),
the wide panel warning indicator blinks
in the control panel.
This does not occur if the camera is not
equipped with communication capability.
2 Slide out the wide panel and place it on
the light-emitting area.
The wide panel indicator lights up in the
control panel.
3 Press the ZOOM button to adjust the
firing angle.
The firing angle can be selected from 8 mm
and 10 mm (16 mm and 20 mm with the
135 type).
When the wide panel is used, the guide
number will be lower, and the available
shooting range or the optimum shooting
distance will be shortened.
ZOOM button
Wide panel
x
Notes
To prevent damage to the wide panel, do not
flip it in the upward direction.
If the wide panel is damaged when it is
slid out, the ZOOM button will no longer be
operable. If that happens, disable the wide
panel switch to restore operability.
g “Custom setup” (P. 28)
