Specifications
Model number : FS-FL36R
Type : External electronic flash for digital still camera
Guide number : Automatic switching
36: When in 42 mm (85 mm with the 135 type)
20: When in 12 mm (24 mm with the 135 type)
12/14 switching (when the wide panel is used)
Firing angle : Automatic switching
At 12 mm: Up/down 61°, Left/right 78°
(equivalent to image angle of 12 mm lens)*
At 42 mm: Up/down 21°, Left/right 28°
(equivalent to image angle of 42 mm lens)*
At 8 mm using the wide panel:
Up/down 83°, Left/right 101°
(equivalent to image angle of 8 mm lens)*
* ZOOM values are the FOUR THIRDS camera
values.
Flash emission period : Approx. 1/20000 to 1/500 sec. (variable according to
the flash intensity, except in Super FP flash)
Flash emission count : Approx. 140 times (using AA (R6) alkaline batteries)
(at full activation) Approx. 320 times (using lithium battery packs)
(Variable depending on shooting conditions)
Recharge time : Approx. 7.5 seconds (using AA (R6) alkaline batteries)
(from full activation to Approx. 6.5 seconds (using lithium battery packs)
CHARGE lamp lighting)
Flash modes : TTL AUTO, AUTO, MANUAL, FP TTL AUTO, FP
MANUAL, RC, SL AUTO, SL MANUAL
Bounce angles : Up: 0 to 90°, down: 7°
Right: 0 to 90°, left: 0 to 180°
Auto power off : Interlocks with the auto power off operation of a
camera with communication capability
AF illuminator : Automatic firing at low intensity, possible only when a
camera with communication capability is connected.
Standard effective distances: 1 to 5 m (3.3 to 16.4 ft.)
(Variable depending on the camera and lens in use.)
r2067e000cs2j.indb54r2067e000cs2j.indb54 2007/10/0110:49:572007/10/0110:49:57

Olympus FL 36R Specifications

General

Product color	Black
Channels quantity	4 channels
Flash guide number	36 m

Weight and Dimensions

Weight	260 g
Dimensions (WxDxH)	67 x 95 x 108 mm
