Olympus USG-400 Service Manual

USG-400
Specifications 2-2 ISSUE1
1 Specifications
○ Ultrasonic Generator USG-400
Rated voltage
120 V AC (USA model)
220 - 240 V AC (EU model)
Voltage fluctuation
Within ±10%
Rated frequency
50/60 Hz
Frequency fluctuation
Within ±1 Hz
Rated input
360VA
Fuse rating
4A,250VA
Power supply
Fuse size
Φ5 X 20mm
Dimensions
375(w)X156(H)X480(D)mm
Size
Weight
9 kg
Type of protection
against electric shock
Class I
Degree of protection
against electric
shock of applied part
CF type
Classification
(medical
electrical
equipment)
Degree of protection
against explosion
The ultrasonic generator should be kept away from
flammable gases.
The applicable
instrument
THUNDERBEAT/SONICBEAT
ON/OFF operation
Footswitch
Handswitch
Output setting
Setting possible in the Set Screen displayed
on the touch panel.
Frequency
47.0kHz
Output
Duty cycle
(Recommended cycle)
1 min. ON/1min. OFF
Medical
Devices
Directive
This device complies with the requirements of Diretive
93/42/EEC concerning medical devices.
Classification: Class Ⅱ b
This device complies with the EMC requirements of EN
60601-1-2:2007 when used in combination with devices
bearing CE marking either on the products or in its
instructions for use.
Emission: Class B of EN 55011
EMC Applied standard
IEC 60601-1-2:2001
(2007)
The ultrasonic generator complies with the standards
listed in the left column.
CISPR 11 of emission:
Group 1,Class B
The ultrasonic generator complies with the EMC standard
for medical electrical equipment; edition 3(IEC
60601-1-2:2007).However, when connecting to an
instrument that complies with the EMC standard for
medical electrical equipment, edition 1(IEC
60601-1-2:1993), the whole system complies with edition
1.
When the ultrasonic generator is combined with the
compatible electrosurgical generator, the EMC
information shall comply with the compatible
electrosurgical generator.
