Olympus USG-400 Service Manual

USG-400
ISSUE1 6-3 Safety check
1-4 Patient leakage current confirmation
○ Criteria
The patient leakage current must not be the value at the table 1-5.
○ Inspection procedures
(1) Turn off the power switch of USG-400.
(2) Connect the Leakage current measuring jig (SS0499) to USG-400, and then connect the
SONICBEAT Transducer with the SONICBEAT instrument (SB-0545PC or SB-0545IC)
attached to it to the opposite side.
USG-400
Leakage current measuring

Olympus USG-400 Specifications

General

Brand	Olympus
Model	USG-400
Category	Portable Generator
Language	English
