BY35S / BY50S / BY80S / BY120S
51
C. Circuit block diagram
D. Related products
Product
Models
BY35S/BY50S BY80S BY120S
Replacement battery pack
BYB50S BYB80S BYB120S
Bracket
BYP50S BYP80S
−
Charging circuit
100 VAC input
“AC input overcurrent protection”
DC-DC
converter
Battery
Inverter circuit
Commercial Power Mode
Battery Mode
Power supply
output receptacle
