Parameter List
11
11.11 o: KEYPAD
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 465
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o2-05
(0509)
LCD FreqRef
Mode@Home Screen
Sets the function that makes it necessary to push the button to change the
frequency reference value with the keypad when in Drive Mode.
0 : Disabled
1 : Enabled
0
(0, 1)
812
o2-06
(050A)
Keypad Disconnect
Detection
Sets the function that stops the drive if you disconnect the keypad connection cable
from the drive or if you damage the cable while the keypad is the Run command source.
0 : Disabled
1 : Enabled
Determined by o2-09
(0, 1)
812
o2-07
(0527)
Keypad Dir@Power-Up
Sets the direction of motor rotation when the drive is energized and the keypad is the
Run command source.
0 : Forward
1 : Reverse
0
(0, 1)
813
o2-09
(050D)
Region Code for
Initialization
- - -
o2-23
(11F8)
Ext24V Off Warning
Display
Sets the function to give a warning when the backup external 24 V power supply turns
off when the main circuit power supply is in operation.
0 : Disabled
1 : Enabled
0
(0, 1)
813
o2-26
(1563)
Ext24V Mode Warning
Display
When you connect a backup external 24 V power supply, this parameter sets the
function to trigger an alarm when the main circuit power supply voltage decreases.
Note:
The drive will not run when it is operating from one 24-V external power supply.
0 : Disabled
1 : Enabled
0
(0, 1)
813
o2-27
(1565)
BLE Disconn.
Selection@BLE Ctrl
Sets drive operation if the Bluetooth device is disconnected when you operate the drive
in Bluetooth Mode.
0 : Ramp->Stop
1 : Coast->Stop
2 : Fast Stop (C1-09)
3 : Alarm Only
4 : No Alarm Display
3
(0 - 4)
813
◆ o3: COPY FUNCTION
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o3-01
(0515)
COPY Keypad Selection
of Mode
Sets the function that saves and copies drive parameters to a different drive with the
keypad.
0 : Copy Select
1 : Bck (Drive->OPE)
2 : Res (OPE->Drive)
3 : Verify (Check)
4 : Del (Clear OPE Memory)
0
(0 - 4)
814
o3-02
(0516)
COPY Allow Selection
Sets the copy function when o3-01 = 1 [COPY Keypad Selection of Mode = Bck
(Drive->OPE)].
0 : Disabled
1 : Enabled
0
(0, 1)
814
o3-04
(0B3E)
COPY Memory
Selection
Sets the storage location for drive parameters when you back up and restore parameters.
This parameter is only available with an LCD keypad.
0 : Memory 1
1 : Memory 2
2 : Memory 3
3 : Memory 4
0
(0 - 3)
814
o3-05
(0BDA)
COPY Items Selection
Sets which parameters are backed up, restored, and referenced. This parameter is only
available with an LED keypad.
0 : Std
1 : Std+Solution
0
(0, 1)
814
To Next Page
