Omron ZEN 10 User Manual

Programmable Relay ZEN 15
Dimensions (Unit: mm)
Precautions
For information on precautions please refer to ZEN operation manual Cat. No. Z183-E1.
CPU Units with 10 I/O Points (LCD/LED Types) With Battery Unit Mounted
CPU Units with 20 I/O Points (LCD/LED Types)
With Battery Unit Mounted
90 80 45
60 44
70 56
ZEN-BAT01
87.5
44 7017.5
45
Q 4
I 6 I 7 I 8 I 9 I a I b
Q 6 Q 5 Q 7
20C1AR-A-V1
90 80
112.5
122.5
45
44
56
Q 4
I 6 I 7 I 8 I 9 I a I b
Q 6 Q 5 Q 7
20C1AR-A-V1
122.517.5
140
45
ZEN-BAT01
44
Expansion I/O Units (4 inputs, 4 outputs, 8 I/O) Unit Mounting Hole (Same for all Units)
90 80
45
44
56
4.5
5.5
